F-5-10 - FRONT BRAKE MASTER CYLINDER
HONDA CB300F MC300AS · 32 parts
Parts in This Assembly (32)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 11152-KS4-003 | CLAMP, PIPE | 1 | |
| 2 | 35340-MGS-D31 | SWITCH ASSY., FR. STOP | 1 | |
| 3 | 38520-K2K-D01 | SENSOR, FR. WHEEL SPEED | 1 | |
| 4 | 38521-K2K-D00 | CLAMPER, SENSOR CORD | 1 | |
| 5 | 45126-K2K-D01 | HOSE COMP. A, FR. BRAKE | 1 | |
| 6 | 45129-K2K-D01 | HOSE COMP. B, FR. BRAKE | 1 | |
| 7 | 45155-K2K-D00 | CLAMPER A, FR. BRAKE HOSE | 1 | |
| 8 | 45156-K2K-D00 | CLAMPER B, FR. BRAKE HOSE | 1 | |
| 9 | 45157-K2K-D00 | CLAMPER C, FR. BRAKE HOSE | 1 | |
| 10 | 45504-410-003 | BOOT COMP. | 1 | |
| 11 | 45510-K2K-D01 | CYLINDER SUB ASSY., FR. BRAKE MASTER(NISSIN) | 1 | |
| 12 | 45512-MA6-006 | PROTECTOR | 1 | |
| 13 | 45513-HA2-006 | CAP, MASTER CYLINDER | 1 | |
| 14 | 45517-166-006 | HOLDER, MASTER CYLINDER | 1 | |
| 15 | 45520-GE2-006 | DIAPHRAGM | 1 | |
| 16 | 45521-K21-901 | PLATE, DIAPHRAGM | 1 | |
| 17 | 45530-471-831 | CYLINDER SET, MASTER | 1 | |
| 18 | 53175-KPN-E01 | LEVER, R. STEERING HANDLE | 1 | |
| 19 | 90106-K43-D20 | BOLT, FLANGE, 6X14(SH) | 1 | |
| 20 | 90114-166-006 | BOLT, HANDLE LEVER PIVOT | 1 | |
| 21 | 90145-GAZ-981 | BOLT, OIL, 10X22 | 2 | |
| 22 | 90302-K1L-D01 | NUT, HEX. CAP, 6MM | 1 | |
| 23 | 90508-K21-921 | SCREW-WASHER, 4X12 | 1 | |
| 24 | 90545-300-000 | WASHER ,OIL BOLT | 4 | |
| 25 | 90651-MA5-671 | CIRCLIP | 1 | |
| 26 | 90690-MCA-003 | CLIP, CABLE, 14MM | 1 | |
| 27 | 93600-04012-1G | SCREW, FLAT, 4X12 | 2 | |
| 28 | 94050-06000 | NUT, FLANGE, 6 MM | 1 | |
| 29 | 96001-06012-07 | BOLT, FLANGE, SH., 6 X 12 | 3 | |
| 30 | 96001-06016-07 | BOLT, FLANGE, SH. 6 X 16 | 1 | |
| 31 | 96001-06022-07 | BOLT, FLANGE, SH.6X22 | 2 | |
| 32 | 96001-06025-07 | BOLT, FLANGE, SH. 6 X 25 | 1 | |
