F-39 - FRAME BODY
HONDA CB Unicorn 160 CBF160H · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50100-K38-910 | BODY COMP., FRAME | 1 | |
| 1 | 50100-K38-900 | BODY COMP., FRAME | 1 | |
| 2 | 50155-K38-900 | GUIDE, MAIN HARNESS | 1 | |
| 3 | 50351-K38-900 | PLATE COMP., FR. ENGINE HANGER | 1 | |
| 4 | 51103-K38-900 | GUARD, SARI | 1 | |
| 5 | 51104-K38-900 | COVER, SARI GUARD | 1 | |
| 6 | 51105-K38-900 | PLATE, SARI GUARD | 1 | |
| 7 | 83560-K38-900 | COVER, R. STEP | 1 | |
| 8 | 83565-K38-900 | COVER, L. STEP | 1 | |
| 9 | 90019-399-010 | BOLT, FLANGE, 10 X 110 | 2 | |
| 10 | 90101-GE0-000 | SCREW, HINGE PATCH | 6 | |
| 11 | 90320-KTE-600 | NUT, SPRING, 5MM | 2 | |
| 14 | 95701-08012-00 | BOLT,FLANGE, 8X12 | 4 | |
| 14 | 95702-08012-00 | BOLT, FLANGE, 8X12 | 4 | |
| 15 | 95701-08038-00 | BOLT FLANGE 8X38 | 1 | |
| 15 | 95702-08038-00 | BOLT, FLANGE, 8X38 | 1 | |
| 16 | 95801-10090-00 | BOLT, FLANGE, 10X90 | 4 | |
