F-25-20 - AIR SUCTION VALVE
HONDA CB Unicorn 160 CBF160H · 19 parts
Parts in This Assembly (19)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 15772-GW3-980 | CLIP, BREATHER TUBE | 1 | |
| 2 | 17365-K38-900 | PLATE, AIR SUCTION VALVE SETTING | 1 | |
| 3 | 17622-GB7-900 | RUBBER, CUSHION | 2 | |
| 4 | 18600-K38-901 | VALVE ASSY., AIR SUCTION | 1 | |
| 5 | 18601-K38-900 | TUBE, SUCTION | 1 | |
| 6 | 18602-K38-900 | TUBE, REED VALVE | 1 | |
| 7 | 18603-K38-900 | TUBE, PB | 1 | |
| 8 | 18640-K38-900 | PIPE COMP., AIR FEED | 1 | |
| 9 | 90417-KSP-900 | WASHER, AIR SUCTION VALVE | 2 | |
| 10 | 90502-KEZ-900 | COLLAR, RUBBER CUSHION | 2 | |
| 11 | 90646-KYJ-DA0 | CLIP, AIR HOSE, 16MM | 1 | |
| 12 | 90678-MR1-690 | CLIP, HOSE | 2 | |
| 13 | 91309-MJ0-003 | O-RING, 9.8 X 2.8 | 1 | |
| 14 | 94050-06000 | NUT, FLANGE, 6 MM | 2 | |
| 15 | 95002-02070 | CLIP, B-7 TUBE | 2 | |
| 16 | 95701-06012-07 | BOLT, FLANGE, 6X12 | 1 | |
| 16 | 95702-06012-07 | BOLT, FLANGE, 6X12 | 1 | |
| 18 | 95701-06030-00 | BOLT, FLANGE, 6X30 | 2 | |
| 18 | 95702-06030-00 | BOLT, FLANGE, 6X30 | 2 | |
