F-7 - HANDLE PIPE/TOP BRIDGE
HONDA CB Unicorn CBF150MH · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 35010-KSP-861 | KEY SET | 1 | |
| 2 | 35100-KSP-861 | SWITCH ASSY., COMBINATION & LOCK | 1 | |
| 3 | 35105-KSP-860 | STAY COMP., COMBINATION SWITCH | 1 | |
| 4 | 35121-KSP-910 | KEY, BLANK | 1 | |
| 5 | 53100-KSP-D00 | PIPE, STEERING HANDLE | 1 | |
| 6 | 53131-KSP-860ZA | HOLDER, HANDLE UPPER *NH35M* CLOUD SILVER METALLIC | 1 | |
| 7 | 53132-KSP-860ZA | HOLDER, HANDLE UNDER *NH35M* CLOUD SILVER METALLIC | 2 | |
| 8 | 53133-KSP-860 | RUBBER, HANDLE CUSHION | 4 | |
| 9 | 53230-KSP-860ZA | BRIDGE, FORK TOP *NH35M* CLOUD SILVER METALLIC | 1 | |
| 10 | 90164-KPL-900 | SCREW, FLAT, U LOCK, 6X12 | 2 | |
| 11 | 90304-K63-D30 | NUT, STEERING STEM | 1 | |
| 12 | 90309-KTE-911 | NUT,FLG PT 8MM | 2 | |
| 13 | 90503-KSP-900 | WASHER, STEERING STEM | 1 | |
| 14 | 90535-KSP-902 | WASHER, HANDLE UNDER HOLDER | 2 | |
| 15 | 91455-KL8-710 | CAP, SOCKET BOLT, 8MM | 4 | |
| 16 | 95701-08040-00 | BOLT, FLANGE, 8 X 40 | 2 | |
| 17 | 96600-08020-00 | BOLT, SOCKET, 8X20 | 2 | |
| 18 | 96600-08032-00 | BOLT FLANGE, 8 X 32 | 4 | |
