F-23-10 - REAR COWL
HONDA CB Unicorn CBF150MH · 16 parts
Parts in This Assembly (16)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 4 | 77260-KSP-D00ZD | COWL SET, R. RR.(WL) *TYPE3 1* | 1 | |
| 4 | 77260-KSP-D00ZE | COWL SET, R. RR.(WL) *TYPE2 1* | 1 | |
| 4 | 77260-KSP-D00ZF | COWL SET, R. RR.(WL) *TYPE1 1* | 1 | |
| 5 | 77270-KSP-D00ZD | COWL SET, L. RR.(WL) *TYPE3 1* | 1 | |
| 5 | 77270-KSP-D00ZE | COWL SET, L. RR.(WL) *TYPE2 1* | 1 | |
| 5 | 77270-KSP-D00ZF | COWL SET, L. RR.(WL) *TYPE1 1* | 1 | |
| 6 | 77280-KSP-A70ZE | COWL SET, RR. CENTER(WL) *NHA04M* GENY GRAY METALLIC | 1 | |
| 6 | 77280-KSP-A70ZA | COWL SET, RR. CENTER(WL) *NHB05P* PEARL IGNEOUS BLACK | 1 | |
| 6 | 77280-KSP-A70ZD | COWL SET, RR. CENTER(WL) *R320P* PEARL SIENA RED | 1 | |
| 7 | 83551-GE2-000 | GROMMET, AIR CLENER CASE | 2 | |
| 9 | 90102-KSP-930 | BOLT, FLANGE, 5X16 | 2 | |
| 12 | 50383-KSP-900 | RUBBER, STOPPER | 1 | |
| 13 | 77235-KSP-860 | STAY, TAILLIGHT | 1 | |
| 14 | 80113-KSP-860 | GROMMET, R. COWL FITTING | 1 | |
| 15 | 80114-KSP-860 | GROMMET, L. COWL FITTING | 1 | |
| 16 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
