F-14-40 - FRONT WHEEL
HONDA CB Unicorn CBF150MH · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 44301-KSP-900 | AXLE, FRONT WHEEL | 1 | |
| 2 | 44311-KSP-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 3 | 44620-KSP-900 | COLLAR FR AXLE DIST | 1 | |
| 4 | 44650-KSP-870 | WHEEL SUB ASSY., FR. | 1 | |
| 5 | 44680-410-000 | RETAINER, GEAR BOX | 1 | |
| 6 | 44711-KFN-852 | TIRE, FR.(2.75-18 42P) | 1 | |
| 7 | 44712-KFN-852 | TUBE(2.75-18) | 1 | |
| 8 | 44800-KSP-900ZC | BOX ASSY., SPEEDOMETER GEAR *NH105* MAT BLACK(#15-#20) | 1 | |
| 9 | 44804-KSP-901 | GEAR, SPEEDOMETER | 1 | |
| 10 | 44809-KPL-900 | WASHER, SPEEDOMETER GEAR | 1 | |
| 11 | 45251-KSP-861 | DISC, FR. BRAKE | 1 | |
| 12 | 90105-KSP-870 | BOLT, FRONT DISK, 8 X 24 | 6 | |
| 13 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 14 | 91251-KPH-901 | DUST SEAL, 21 X 37 X 7 | 1 | |
| 15 | 91258-410-013 | DUST SEAL, 40X50X5(ARAI) | 1 | |
| 16 | 96150-63010-10 | BEARING, BALL RADIAL, 6301 (UU) | 2 | |
| 17 | 44820-KSP-900 | GEAR SET, SPEEDOMETER | 1 | |
