F-42 - FRAME BODY
HONDA Activa SCV110P/SR · 20 parts
Parts in This Assembly (20)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 11345-K0L-D00 | DUCT, L. COVER | 1 | |
| 2 | 11346-K0L-D00 | BAND, AIR CLEANER CONNECTING TUBE(40) | 1 | |
| 3 | 50100-K0P-D00 | BODY COMP., FRAME | 1 | |
| 4 | 50127-K0P-D00 | GUIDE COMP., CABLE | 1 | |
| 5 | 50352-K0L-D00 | RUBBER, LINK STOPPER | 1 | |
| 6 | 50354-K0L-D00 | GUARD, ENGINE HANGER LINK | 1 | |
| 7 | 50355-K0L-D00 | LINK SUB ASSY., ENGINE HANGER | 1 | |
| 8 | 80102-K0L-D00 | PLATE, FRAME BODY SPLASH GUARD | 1 | |
| 9 | 81256-K0L-D00 | ROD, BODY OPENER | 1 | |
| 10 | 90105-K0L-D00 | BOLT, FLANGE, 10X185 | 1 | |
| 11 | 90304-KTE-911 | NUT, FLANGE SPECIAL, 10MM (SIMMONDS MARSHALL) | 3 | |
| 12 | 90651-K0L-D01 | CLAMPER, THROTTLE CABLE | 1 | |
| 13 | 90652-K0L-D01 | CLIP, SPLASH GUARD | 7 | |
| 14 | 91405-KPL-900 | CLAMP, D29 TUBE | 1 | |
| 15 | 95702-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 15 | 95701-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 16 | 95701-08032-08 | BOLT, FLANGE, 8X32 | 2 | |
| 16 | 95702-08032-08 | BOLT, FLANGE, 8X32 | 2 | |
| 17 | 95801-10055-08 | BOLT, FLANGE, 10X55 | 2 | |
| 18 | 50330-K0P-D00 | STAY COMP., FR. COVER | 1 | |
