F-15 - BODY COVER
HONDA Activa SCV110P/SR · 52 parts
Parts in This Assembly (52)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 16530-K0L-D00 | CATCH COMP., FUEL LID | 1 | |
| 2 | 17507-K0L-D00 | PIN, FUEL LID | 1 | |
| 3 | 64451-K0P-D00 | SPRING, FUEL LID OPENER | 1 | |
| 4 | 64452-K0L-D00 | BAR, FUEL LID LOCK | 1 | |
| 5 | 64455-K0L-602 | CABLE COMP., FUEL LID(SEL) | 1 | |
| 5 | 64455-K0L-D02 | CABLE COMP., FUEL LID(HI-LEX) | 1 | |
| 6 | 77234-GN2-000 | SPRING, SEAT LOCK | 1 | |
| 7 | 77300-K0P-D00ZA | SPRING, SEAT LOCK GRIP, RR. *NH35M* CLOUD SILVER METALLIC | 1 | |
| 8 | 80151-K0P-D00ZA | COVER, CENTER *NH1* BLACK | 1 | |
| 9 | 81132-KWP-H00ZA | HOOK, LUGGAGE *NH1* BLACK | 1 | |
| 10 | 83500-K0P-P00ZZ | COVER COMP., R. BODY | 1 | |
| 11 | 83504-K0P-D00 | MEMBER COMP., R. BODY COVER | 1 | |
| 12 | 83510-K0L-P00ZZ | STAY, FR. BODY COVER | 1 | |
| 13 | 83520-K0P-D00ZA | MOUL, R. BODY COVER *NH1* BLACK | 1 | |
| 14 | 83560-K0P-D00 | HINGE, BODY COVER | 1 | |
| 15 | 83561-KPL-840 | CUSHION, BODY COVER | 2 | |
| 16 | 83600-K0P-P00ZZ | COVER COMP., L. BODY | 1 | |
| 17 | 83604-K0P-D00 | MEMBER COMP., L. BODY COVER | 1 | |
| 18 | 83620-K0P-D00ZA | MOUL, L. BODY COVER *NH1* BLACK | 1 | |
| 19 | 83750-K0P-D00ZC | COVER, RR. CENTER UPPER(WOL) *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 19 | 83750-K0P-D00ZD | COVER, RR. CENTER UPPER(WOL) *NH1* BLACK | 1 | |
| 19 | 83750-K0P-D00ZP | COVER, RR. CENTER UPPER(WOL) *NHC41P* PEARL PRECIOUS WHITE | 1 | |
| 19 | 83750-K0P-D00ZQ | COVER, RR. CENTER UPPER(WOL) *B236M* DECENT BLUE METALLIC | 1 | |
| 19 | 83750-K0P-D00ZS | COVER, RR. CENTER UPPER *Y236M* DAZZLE YELLOW METALLIC 2 | 1 | |
| 19 | 83750-K0P-D00ZU | COVER, RR. CENTER UPPER *R392P* PEARL SPARTAN RED 2 | 1 | |
| 20 | 83751-K0P-D00ZC | COVER, RR. CENTER LOWER *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 20 | 83751-K0P-D00ZD | COVER, RR. CENTER LOWER *NH1* BLACK | 1 | |
| 20 | 83751-K0P-D00ZP | COVER, RR. CENTER LOWER *NHC41P* PEARL PRECIOUS WHITE | 1 | |
| 20 | 83751-K0P-D00ZQ | COVER, RR. CENTER LOWER *B236M* DECENT BLUE METALLIC | 1 | |
| 20 | 83751-K0P-D00ZS | COVER, RR. CENTER LOWER *Y236M* DAZZLE YELLOW METALLIC 2 | 1 | |
| 20 | 83751-K0P-D00ZU | COVER, RR. CENTER LOWER *R392P* PEARL SPARTAN RED 2 | 1 | |
| 21 | 83801-K0P-D00ZC | LID, FUEL *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 21 | 83801-K0P-D00ZD | LID, FUEL *NH1* BLACK | 1 | |
| 21 | 83801-K0P-D00ZP | LID, FUEL *NHC41P* PEARL PRECIOUS WHITE | 1 | |
| 21 | 83801-K0P-D00ZQ | LID, FUEL *B236M* DECENT BLUE METALLIC | 1 | |
| 21 | 83801-K0P-D00ZS | LID, FUEL *Y236M* DAZZLE YELLOW METALLIC 2 | 1 | |
| 21 | 83801-K0P-D00ZU | LID, FUEL *R392P* PEARL SPARTAN RED 2 | 1 | |
| 22 | 83802-K0P-D00 | BASE, FUEL LID | 1 | |
| 23 | 83803-K0P-D00 | COVER, FUEL LID CATCH | 1 | |
| 24 | 90101-K0L-D00 | RUBBER, SETTING | 2 | |
| 25 | 90109-K0P-D00 | BOLT, SPECIAL, 6MM | 1 | |
| 26 | 90116-SP0-003 | CLIP, BUMPER SEAL | 2 | |
| 27 | 90651-K14-A31 | CLIP, SLIDE | 4 | |
| 28 | 90654-K0L-D00 | NUT, CLIP, 5MM | 2 | |
| 29 | 91509-GE2-760 | SCREW, WASHER, 5 X 11.5 | 4 | |
| 30 | 93903-24310 | SCREW, TAPPING, 4X12 | 1 | |
| 31 | 93903-34480 | SCREW, TAPPING, 4X 16 | 8 | |
| 33 | 95702-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
| 34 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
| 35 | 95702-08022-00 | BOLT, FLANGE, 8X22 | 2 | |
| 36 | 95702-08032-00 | BOLT, FLANGE, 8X32 | 2 | |
| 37 | 96001-06010-00 | BOLT FLANGE SH. 6×10 | 2 | |
