F-22-4 - WIRE HARNESS(SCV110E)
HONDA Activa SCV110E · 36 parts
Parts in This Assembly (36)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 30410-KWP-E01 | SPARK UNIT COMP.(DENSO) | 1 | |
| 1 | 30410-KWP-E02 | SPARK UNIT COMP.(SHINDENGEN) | 1 | |
| 2 | 30500-KWP-D21 | COIL ASSY., IGNITION(JAGDISH) | 1 | |
| 2 | 30500-KWP-D01 | COIL ASSY., IGNITION(WINGS) | 1 | |
| 3 | 30520-GFM-900 | SPACER, IGNITION COIL | 2 | |
| 4 | 30700-KWP-901 | CAP ASSY NOISE SUPPRESSOR | 1 | |
| 4 | 30700-KWP-D01 | CAP ASSY., NOISE SUPPRESSOR(MINDA) | 1 | |
| 5 | 31600-KWP-E01 | RECTIFIER COMP., REGULATE(SHINDENGEN) | 1 | |
| 5 | 31600-KWP-E02 | RECTIFIER COMP., REGULATE(STAR ENGINEERS) | 1 | |
| 6 | 32100-KWP-E10 | HARNESS, WIRE(MINDA SAI) | 1 | |
| 6 | 32100-KWP-E30 | HARNESS, WIRE(SUMITOMO MOTHERSON) | 1 | |
| 6 | 32100-KWP-E20 | HARNESS, WIRE(SUMITOMO MOTHERSON) | 1 | |
| 6 | 32100-KWP-E00 | HARNESS, WIRE(MINDA SAI) | 1 | |
| 7 | 35011-KWP-D20 | SHUTTER SET, KEY(MINDA)(KEY NO. RXXX/SXXX) | 1 | |
| 7 | 35011-KWP-910 | SHUTTER SET, KEY(JAY USHIN)(KEY NO. PXXX/QXXX) | 1 | |
| 8 | 35012-KWP-D00 | SWITCH ASSY. SET, COMBINATION& LOCK(JAY USHIN) | 1 | |
| 8 | 35012-KWP-D20 | SWITCH ASSY. SET, COMBINATION& LOCK(MINDA) | 1 | |
| 9 | 35014-KWP-D20 | KEY & SCREW SET(MINDA) | 1 | |
| 9 | 35014-KWP-D00 | KEY & SCREW SET(JAY USHIN) | 1 | |
| 10 | 35121-KWP-D20 | (D2KEYTOP2REPORDER)(KEY NO. RXXX/SXXX) | 1 | |
| 10 | 35121-KWP-910 | KEY, BLANK(91KEYTOP2REPORDER) | 1 | |
| 11 | 38110-KWP-901 | HORN COMP. | 1 | |
| 12 | 38301-KWP-D21 | RELAY COMP., WINKER(STAR ENGINEERS) | 1 | |
| 12 | 38301-KZK-901 | RELAY COMP., WINKER | 1 | |
| 13 | 38501-KPL-901 | RELAY COMP., STARTER(MULTILINK) | 1 | |
| 13 | 38501-KWH-971 | RELAY COMP,START | 1 | |
| 14 | 90164-KPL-900 | SCREW, FLAT, U LOCK, 6X12 | 2 | |
| 15 | 90657-KRP-901 | CABLE, TIE(LONG) | 1 | |
| 16 | 92101-06020-4J | BOLT, HEX., 6 X 20 | 2 | |
| 17 | 95701-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 17 | 95702-06012-00 | BOLT, FLANGE, 6X12 | 1 | |
| 19 | 95702-06016-00 | BOLT, FLANGE, 6X16 | 1 | |
| 20 | 95701-06016-08 | BOLT, FLANGE, 6X16 | 1 | |
| 20 | 95702-06016-08 | BOLT, FLANGE, 6X16 | 1 | |
| 21 | 98200-31000 | BLADE, FUSE 10A | 4 | |
| 22 | 98200-31500 | BLADE, FUSE, 15A | 4 | |
