F-21-2 - BATTERY(SCV110B,D,E)
HONDA Activa SCV110E · 6 parts
Parts in This Assembly (6)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KVT-941 | BATTERY ASSY.,MF4 | 1 | |
| 2 | 50325-KWP-940 | BOX, BATTERY UPPER | 1 | |
| 3 | 50326-KWP-940 | BOX, BATTERY LOWER | 1 | |
| 4 | 50341-KWP-940 | BAND BATTERY | 1 | |
| 5 | 95003-12046-10 | V.TUBE 5X7X460 | 1 | |
| 6 | 95702-06012-08 | BOLT, FLANGE, 6X12 | 1 | |
