F-1-1 - HEADLIGHT(SCV110D,E)(LUMAX)
HONDA Activa SCV110E · 12 parts
Parts in This Assembly (12)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33120-KWP-901 | HEADLIGHT UNIT | 1 | |
| 1 | 33110-KWP-D10 | HEADLIGHT UNIT(12V 35/35W) | 1 | |
| 2 | 33126-KTP-890 | COVER, RUBBER | 1 | |
| 3 | 33128-GBL-003 | NUT, SPECIAL | 1 | |
| 4 | 33150-KWP-D10 | SOCKET ASSY., POSITION LIGHT | 1 | |
| 5 | 34901-KSP-910 | BULB, HEAD LIGHT | 1 | |
| 5 | 34901-KTE-740 | BULB, HEADLIGHT(HS1) (12V 35/35W)(PHILIPS) | 1 | |
| 5 | 34901-KVN-971 | BULB HEAD LIGHT | 1 | |
| 6 | 34903-KRP-980 | BULB, POSITION LIGHT(12V 5W) | 1 | |
| 7 | 53209-GAH-000 | CLIP, HEADLIGHT | 2 | |
| 8 | 90103-KVH-900 | BOLT, ADJUST | 1 | |
| 9 | 90307-GW3-980 | WASHER, LOCK, 6MM | 1 | |
