F-7 - FLOOR PANEL
HONDA Eterno SC1504 · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50621-KRB-901 | COVER, UNDER | 1 | |
| 2 | 50624-KRB-901 | RUBBER R, PROTECTOR | 1 | |
| 3 | 64310-KRB-900ZA | PANEL, FLOOR *NH1* BLACK | 1 | |
| 4 | 64315-KRB-900 | COVER, RR. BRAKE PEDAL | 1 | |
| 5 | 93404-06012-08 | BOLT-WASHER, 6X12 | 4 | |
| 6 | 90001-KRB-900 | BOLT-WASHER, 6X20 | 4 | |
| 7 | 93894-05012-08 | SCREW-WASHER, 5X12 | 2 | |
| 9 | 50634-KRB-900 | RUBBER L, PROTECTOR | 1 | |
