F-16-1 - AIR SUCTION VALVE
HONDA Eterno SC1504 · 13 parts
Parts in This Assembly (13)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 2 | 17622-GB7-900 | RUBBER, CUSHION | 2 | |
| 3 | 18600-KRB-901 | VALVE ASSY., AIR SUCTION | 1 | |
| 4 | 18640-KRB-900 | PIPE COMP., AIR FEED | 1 | |
| 5 | 18645-KRB-900 | GASKET, AIR FEED PIPE | 1 | |
| 6 | 18651-KRB-900 | TUBE, AIR SUCTION VALVE | 1 | |
| 7 | 18652-KRB-900 | HOSE, AIR SUCTION VALVE | 1 | |
| 8 | 18653-KRB-901 | TUBE COMP., AIR SUCTION VALVE | 1 | |
| 9 | 90501-KC2-750 | WASHER, REGULATOR SETTING | 2 | |
| 10 | 91462-KM7-910 | CLIP, TUBE | 2 | |
| 11 | 93404-06030-08 | BOLT WASH 6X30 | 2 | |
| 12 | 94050-06000 | NUT, FLANGE, 6 MM | 2 | |
| 13 | 95002-02070 | CLIP, B-7 TUBE | 2 | |
| 15 | 96001-06016-00 | BOLT, FLANGE SH. 6 X 16 | 2 | |
