F-6 - FRONT COVER
HONDA Eterno SC1504 · 15 parts
Parts in This Assembly (15)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 04644-KRB-900ZZ | COVER COMP., R. FR. | 1 | |
| 2 | 04645-KRB-900ZZ | COVER COMP., L. FR. | 1 | |
| 3 | 64200-KRB-900ZA | COVER, FR. CENTER (WOL) *BG126M* FAB GREEN METALLIC | 1 | |
| 3 | 64200-KRB-900ZB | COVER, FR. CENTER (WOL) *B172M* AZURE BLUE METALLIC | 1 | |
| 3 | 64200-KRB-900ZC | COVER, FR. CENTER (WOL) *GY125* GRAYISH GREEN | 1 | |
| 3 | 64200-KRB-900ZD | COVER, FR. CENTER (WOL) *NH1* BLACK | 1 | |
| 3 | 64200-KRB-900ZE | COVER, FR. CENTER (WOL) *Y179M* SILVERY BEIGE METALLIC | 1 | |
| 4 | 81131-KRB-900ZA | COVER, INNER *NH1* BLACK | 1 | |
| 5 | 84702-KRB-900 | COLLAR, FR. NUMBER PLATE | 2 | |
| 6 | 90111-KPL-900 | BOLT, INNER COVER | 1 | |
| 7 | 90203-KEJ-900 | NUT, FLANGE CAP, 5MM | 2 | |
| 8 | 90344-KRB-900 | NUT, CLIP, 5MM | 12 | |
| 9 | 90381-GT8-000 | SCREW, SPECIAL, 6X11 | 2 | |
| 11 | 93903-35310 | SCREW TAPPING 5X16 | 2 | |
| 13 | 95701-06050-00 | BOLT, FLANGE, 6 X 50 | 2 | |
