F-3 - HANDLE LEVER/SWITCH/CABLE
HONDA Eterno SC1504 · 38 parts
Parts in This Assembly (38)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17910-KRB-901 | CABLE COMP., THROTTLE | 1 | |
| 2 | 17950-KRB-900 | CABLE COMP., CHOKE | 1 | |
| 3 | 22870-KRB-901 | CABLE COMP., CLUTCH | 1 | |
| 4 | 24711-KRB-900 | CABLE COMP. A, CHANGE | 1 | |
| 5 | 24712-KRB-900 | CABLE COMP. B, CHANGE | 1 | |
| 6 | 35150-KRB-901 | SWITCH UNIT, LIGHTING (MINDA) | 1 | |
| 6 | 35150-KRB-902 | SWITCH UNIT, LIGHTING (J-USHIN) | 1 | |
| 7 | 35170-KRB-901 | SWITCH UNIT, DIMMER (MINDA) | 1 | |
| 7 | 35170-KRB-902 | SWITCH UNIT, DIMMER (J-USHIN) | 1 | |
| 8 | 35180-KRB-901 | SWITCH UNIT, HORN (MINDA) | 1 | |
| 8 | 35180-KRB-902 | SWITCH UNIT, HORN (J-USHIN) | 1 | |
| 9 | 35200-KRB-901 | SWITCH UNIT, WINKER (MINDA) | 1 | |
| 9 | 35200-KRB-902 | SWITCH UNIT, WINKER (J-USHIN) | 1 | |
| 10 | 35340-KPL-900 | SWITCH ASSY., FR. STOP | 1 | |
| 11 | 45450-KPL-900 | CABLE COMP., FR. BRAKE | 1 | |
| 12 | 53101-KRB-900 | PIPE COMP., CHANGE | 1 | |
| 13 | 53102-KRB-900 | BEARING, HANDLE | 2 | |
| 14 | 53103-KRB-900 | CLIP, PIN | 1 | |
| 15 | 53104-KRB-900 | PULLEY, CHANGE | 1 | |
| 16 | 53140-KRB-900 | GRIP COMP., L. HANDLE | 1 | |
| 17 | 53142-KRB-900 | CAP, CHANGE PIPE END | 1 | |
| 18 | 53146-KRB-900 | GRIP COMP., THROTTLE | 1 | |
| 19 | 53167-KPL-900 | HOUSING , UPP., THROT | 1 | |
| 20 | 53168-KPL-900 | HOUSING, UNDER THROTTLE | 1 | |
| 21 | 53175-KPL-900 | LEVER, R. STEERING HANDLE | 1 | |
| 22 | 53178-KRB-901 | LEVER, L. HANDLE | 1 | |
| 23 | 88110-KRB-901 | MIRROR ASSY., R. BACK | 1 | |
| 24 | 88112-KRB-900 | CAP, LOCK NUT | 2 | |
| 25 | 88120-KRB-901 | MIRROR ASSY., L. BACK | 1 | |
| 26 | 90105-KEM-900 | BOLT, FLANGE, 6X16 | 1 | |
| 27 | 90115-KPL-900 | SCREW, HNDL LEVER PIVOT | 1 | |
| 28 | 90115-KRB-900 | SCREW, HANDLE LEVER PIVOT | 1 | |
| 29 | 90134-GM8-000 | NUT, LOCK | 1 | |
| 30 | 90135-KGF-900 | NUT, LOCK L.H. | 1 | |
| 31 | 90302-KRB-900 | WASHER, SPECIAL | 1 | |
| 32 | 90304-KPL-900 | NUT HEX 5 MM | 2 | |
| 33 | 93401-06020-00 | BOLT, WASHER, 6 X 20 | 1 | |
| 34 | 93903-24380 | SCREW TAPPING, 4 X 12 | 1 | |
