F-20 - STAND
HONDA Eterno SC1504 · 5 parts
Parts in This Assembly (5)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50500-KRB-900 | STAND COMP., MAIN | 1 | |
| 2 | 50503-KRB-900 | SHAFT, MAIN STAND | 1 | |
| 3 | 50523-KRB-900 | SPRING, MAIN STAND | 1 | |
| 4 | 94102-12000 | WASHER, PLAIN, 12MM | 1 | |
| 5 | 94201-25250 | PIN, SPLIT, 2.5X25 | 1 | |
