F-2 - METER
HONDA Eterno SC1504 · 13 parts
Parts in This Assembly (13)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 34908-KPL-901 | BULB(12V/3.0W) | 1 | |
| 2 | 34909-KPL-901 | BULB(12V/1.7W) | 2 | |
| 3 | 37200-KRB-901 | SPEEDOMETER ASSY. | 1 | |
| 4 | 37210-KRB-901 | SPEEDOMETER COMP. | 1 | |
| 5 | 37211-KRB-901 | LENS | 1 | |
| 6 | 37215-KAF-008 | CLAMP | 1 | |
| 7 | 37220-KRB-901 | CASE ASSY. | 1 | |
| 8 | 37224-KRB-901 | SOCKET COMP. | 1 | |
| 9 | 44830-KPL-900 | CABLE COMP., SPEEDOMETER | 1 | |
| 10 | 44831-KPL-900 | CABLE, INNER | 1 | |
| 11 | 90035-166-008 | SCREW-WASHER, SPECIAL, 4X10 | 2 | |
| 12 | 93903-24420 | SCREW,TAPPING,4 X 16 | 1 | |
| 13 | 93903-25320 | SCREW, TAPPING, 5 X 16 | 3 | |
