F-18 - KICK STARTER ARM/BRAKE PEDAL
HONDA Eterno SC1504 · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 28301-KRB-902 | ARM, KICK STARTER | 1 | |
| 2 | 35350-KRB-901 | SWITCH ASSY., RR. STOP | 1 | |
| 3 | 35357-KJ9-000 | SPRING, STOP SWITCH | 1 | |
| 4 | 43450-KRB-900 | CABLE COMP., RR. BRAKE | 1 | |
| 5 | 46501-KRB-900 | PEDAL COMP., RR. BRAKE | 1 | |
| 6 | 46502-KRB-900 | COVER, BRAKE PEDAL | 1 | |
| 7 | 46514-KZ9-000 | SPRING, BRAKE PEDAL | 1 | |
| 8 | 90657-KRP-901 | CABLE, TIE(LONG) | 1 | |
| 9 | 95701-08030-07 | BOLT, FLANGE 8X30 | 1 | |
