F-17 - EXHAUST MUFFLER
HONDA Eterno SC1504 · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 18291-GA7-000 | GASKET, EX. PIPE | 1 | |
| 2 | 18292-GW3-980 | PACKING, PROTECTOR | 4 | |
| 3 | 18300-KRB-900 | MUFFLER COMP., EX. | 1 | |
| 4 | 18318-KRB-900 | PROTECTOR, MUFFLER | 1 | |
| 5 | 90305-KFN-850 | NUT, HEX CAP, 7MM | 2 | |
| 6 | 94101-06700 | WASHER, PLAIN, 6 MM | 2 | |
| 7 | 95801-10070-08 | BOLT, FLANGE, 10X70 | 2 | |
| 8 | 96001-06012-07 | BOLT, FLANGE, SH., 6 X 12 | 2 | |
