F-15 - REAR FENDER
HONDA Eterno SC1504 · 6 parts
Parts in This Assembly (6)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33741-KPL-901 | REFLECTOR, REFLEX | 1 | |
| 2 | 80104-KRB-900 | PLATE, RR. FENDER SPLASH GUARD | 1 | |
| 3 | 80105-KRB-900ZA | FENDER, RR. *NH1* BLACK | 1 | |
| 4 | 90301-KRP-900 | NUT, PLATE | 2 | |
| 5 | 93404-06012-08 | BOLT-WASHER, 6X12 | 2 | |
| 6 | 94050-05000 | NUT FLANGE, 5 MM | 1 | |
