F-10 - STEERING STEM/FRONT FORK
HONDA Eterno SC1504 · 26 parts
Parts in This Assembly (26)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50301-KEM-900 | RACE, UP STRG., BALL | 1 | |
| 2 | 50302-268-010 | RACE, STEERING BOTTOM BALL | 1 | |
| 3 | 50306-KPL-900 | NUT, STRG. STEM, LOCK | 1 | |
| 4 | 51110-KRB-900 | FORK SET, FR. | 1 | |
| 5 | 51314-KPL-900 | BUSH, PIVOT ARM | 4 | |
| 6 | 51315-KRB-900 | ARM SET, R. PIVOT | 1 | |
| 7 | 51316-KPL-900 | CAP, FR. DISTANCE COLLAR | 4 | |
| 8 | 51334-KPL-900 | COLLAR, ARM, PIVOT | 2 | |
| 9 | 51400-KRP-982 | CUSHION ASSY., R. FR | 1 | |
| 10 | 51413-GC8-003 | BUSH, FR. CUSHION UNDER | 4 | |
| 11 | 51415-KRB-900 | ARM SET, L. PIVOT | 1 | |
| 12 | 51486-GC8-003 | COLLAR, RUBBER, BUSH | 2 | |
| 13 | 51500-KRP-982 | CUSHION ASSY., L. FR | 1 | |
| 14 | 51486-KRP-981 | COLLAR, FR. CUSHION, RUBBER BUSH | 2 | |
| 15 | 52489-331-003 | RUBBER, A JOINT | 2 | |
| 16 | 53211-KEM-900 | RACE, STRG. TOP CONE | 1 | |
| 17 | 53212-250-010 | RACE, STRG. BOTTOM CONE | 1 | |
| 18 | 53214-250-000 | DUST, SEAL STRG. (HEAD) | 1 | |
| 19 | 53215-KPL-900 | WASHER, STRG. HEAD DUST SEAL | 1 | |
| 20 | 90121-KPL-900 | BOLT, HEX., 8X32 | 2 | |
| 22 | 90443-KPL-900 | WASHER,SPECIAL, 8MM | 2 | |
| 23 | 90506-KPL-900 | WASHER, LOCK NUT | 1 | |
| 24 | 91351-KPL-900 | O-RING,22.1 X 1.9 | 4 | |
| 25 | 95801-08055-08 | BOLT, FLANGE, 8 X 55 | 2 | |
| 26 | 96211-05000 | BALL, STEEL #5 | 26 | |
| 27 | 96211-08000 | BALL STEEL 8 MM | 19 | |
