F-20-30 - FRONT WHEEL
HONDA CLIQ NVB110H · 38 parts
Parts in This Assembly (38)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 06430-KWP-900 | SHOE SET, BRAKE(JB) | 1 | |
| 1 | 06430-KWP-D00 | SHOE SET, BRAKE(ASK) | 1 | |
| 2 | 42711-K83-D01 | TIRE(CEAT)(90/100-10 53J) | 1 | |
| 2 | 42711-K83-D02 | TIRE(MRF)(90/100-10 53J) | 1 | |
| 3 | 42753-K24-G01 | VALVE, RIM(ACCURA) | 1 | |
| 3 | 42753-KWP-E01 | VALVE, RIM(TRITON) | 1 | |
| 4 | 44301-KPL-900 | AXLE, FRONT WHEEL | 1 | |
| 5 | 44311-KPL-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 6 | 44620-KPL-900 | COLLAR FR WHEEL DISTANCE | 1 | |
| 7 | 44650-KZK-D20 | WHEEL SUB ASSY., FR. | 1 | |
| 7 | 44650-KZK-D21 | WHEEL SUB ASSY., FR........... | 1 | |
| 8 | 44809-KPL-900 | WASHER, SPEEDOMETER GEAR | 1 | |
| 9 | 44811-KPL-900 | GEAR, SPDMT | 1 | |
| 10 | 45010-KZK-910 | PANEL SUB COMP., FR. BRAKE | 1 | |
| 11 | 43151-329-000 | SPRING, BRAKE SHOE (ASK) | 2 | |
| 11 | 45133-KPL-900 | SPRING, FR.BRAKE SHOE (ASK)(FOR RR.) | 2 | |
| 12 | 45134-250-000 | DUST SEAL, BRAKE CAM | 1 | |
| 13 | 45141-KWP-D00 | CAM, FR. BRAKE (RR.) | 1 | |
| 14 | 45145-KPL-900 | INDICATOR, FRONT BRAKE | 1 | |
| 15 | 45410-KWP-E00 | ARM COMP., FR. BRAKE | 1 | |
| 16 | 45435-KPL-900 | SPRING, BRAKE ARM RETURN | 1 | |
| 17 | 45453-KWP-G30 | JOINT, BRAKE ARM | 2 | |
| 18 | 45456-KWP-910 | SPRING BRK CABLE END | 2 | |
| 19 | 45459-KWP-911 | NUT BRAKE ADJUSTING | 2 | |
| 20 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 21 | 90912-KPL-900 | BEARING BALL RADIAL 6201(U) | 2 | |
| 21 | 91052-K0L-D01 | BEARING, RADIAL BALL, 6201U (FAG) | 2 | |
| 22 | 91251-KWP-901 | SEAL DUST 20X32X5 | 1 | |
| 23 | 91253-KPL-900 | DUST SEAL , 41 X60 X7 | 1 | |
| 24 | 94050-06000 | NUT, FLANGE, 6 MM | 1 | |
| 25 | 95701-06035-00 | BOLT, FLANGE, 6X35 | 1 | |
| 25 | 95702-06035-00 | BOLT, FLANGE, 6X35 | 1 | |
| 26 | 44820-KWP-900 | GEAR SET, SPEEDOMETER | 1 | |
| 27 | 45134-KWP-G30 | SPRING, BRAKE ARM JOINT | 1 | |
| 28 | 44660-KZK-D20 | RIM SET, WHEEL................ | 1 | |
| 29 | 44670-KZK-D20 | HUB SET, WHEEL................ | 1 | |
| 30 | 90304-KTE-911 | NUT, FLANGE SPECIAL, 10MM (SIMMONDS MARSHALL) | 4 | |
| 30 | 90304-KST-942 | NUT FLG.PT 10MM | 4 | |
