F-14 - FLOOR STEP
HONDA CLIQ NVB110H · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 50621-K83-D00 | COVER, UNDER | 1 | |
| 2 | 64310-K83-D00ZA | STEP, FLOOR *NH1* BLACK | 1 | |
| 3 | 64311-K83-D00ZA | LID, FLOOR *NH1* BLACK | 1 | |
| 4 | 90111-187-000 | BOLT, FLANGE. 6 MM | 4 | |
| 5 | 90150-MBG-000 | SCREW, PAN, 5X15 | 2 | |
| 6 | 90320-GC3-000 | NUT, SPRING, M5 | 4 | |
| 7 | 91509-GE2-760 | SCREW, WASHER, 5 X 11.5 | 6 | |
| 8 | 93404-06016-08 | BOLT, WASH, 6X16 | 4 | |
| 9 | 93903-34380 | SCREW, TAPPING, 4X12 | 2 | |
