F-25 - AIR CLEANER
HONDA Shine100 DX CD100RNT · 12 parts
Parts in This Assembly (12)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17210-K3C-D10 | ELEMENT COMP., AIR CLEANER | 1 | |
| 2 | 17214-K3C-D10 | SEAL, AIR CLEANER | 1 | |
| 3 | 17219-K3C-D10 | DUCT, AIR CLEANER | 1 | |
| 4 | 17225-K3C-D10 | CASE SUB ASSY., AIR CLEANER | 1 | |
| 5 | 17227-KYY-900 | V.TUBE 11X15X40 | 1 | |
| 7 | 17245-K3C-D10 | COVER SUB ASSY., AIR CLEANER | 1 | |
| 8 | 17253-K3C-D10 | TUBE, AIR CLEANER CONNECTING · | 1 | |
| 9 | 17255-K0N-D80 | BAND, AIR CLEANER CONNECTING TUBE(48) | 1 | |
| 10 | 17371-K3C-D10 | TUBE, BREATHER | 1 | |
| 11 | 90111-162-000 | BOLT, FLANGE, 6MM | 1 | |
| 12 | 90653-KWP-F00 | CLIP, TUBE(B12.5) | 3 | |
| 13 | 91406-KFN-850 | CLAMP, D14.5 TUBE | 1 | |
