F-26 - CANISTER
HONDA CBR650R CBR650RAN · 18 parts
Parts in This Assembly (18)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17411-MJE-TB0 | RUBBER, CANISTER MOUNT | 1 | |
| 2 | 17412-MJE-L00 | TUBE(PCSV-THROTTLE BODY) | 1 | |
| 3 | 17413-MJE-L00 | TUBE(PCSV-CANISTER) | 1 | |
| 4 | 17414-MJE-TB0 | TUBE, AIR | 1 | |
| 5 | 17420-MGZ-A02 | CANISTER COMP. | 1 | |
| 6 | 17430-MJE-L00 | STAY COMP. A, CANISTER | 1 | |
| 7 | 17430-MJE-TB0 | GUARD, HEAT | 1 | |
| 8 | 17440-MJE-L00 | STAY COMP. B, CANISTER | 1 | |
| 9 | 17580-MJE-T10 | TUBE, CANISTER | 1 | |
| 10 | 33115-KVK-900 | RUBBER, HEADLIGHT | 1 | |
| 11 | 36162-MKA-D81 | VALVE, PURGE CONTROL SOLENOID | 1 | |
| 13 | 64382-MM5-300 | TAPE, COVER | 1 | |
| 14 | 90002-892-000 | BOLT, FLANGE, 5X10 | 2 | |
| 15 | 95001-45320-40 | TUBE, FUEL, 4.5X320 (95001-45001-60M) | 1 | |
| 16 | 95002-40800-08 | CLAMP D 8.0 TUBE | 1 | |
| 17 | 95002-41000-08 | CLAMP, TUBE(D10) | 1 | |
| 18 | 95701-06010-00 | BOLT, FLANGE, 6 X 10 | 2 | |
| 20 | 95701-06022-08 | BOLT, FLANGE, 6X22 | 1 | |
