F-24-10 - SARI GUARD
HONDA CBR650R CBR650RAN · 13 parts
Parts in This Assembly (13)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 18421-KBA-900 | RUBBER, MUFFLER MOUNTING | 1 | |
| 2 | 18422-KBA-900 | COLLAR, MUFFLER MOUNTING | 1 | |
| 3 | 51103-MKY-S10 | GUARD COMP., SARI | 1 | |
| 4 | 51104-MKN-S10 | BRACKET, SARI GUARD | 1 | |
| 5 | 51107-MKN-S10 | COLLAR, SARI GUARD | 2 | |
| 6 | 51110-MKY-S10 | BRACKET, R. SARI | 1 | |
| 7 | 61103-KRY-900 | COLLAR, A FR.FENDER | 1 | |
| 8 | 90085-MAJ-A20 | BOLT, SPECIAL, 6X22 | 1 | |
| 9 | 90105-MKN-S10 | BOLT, SOCKET, 8X65 | 2 | |
| 10 | 90852-898-000 | RUBBER, CONTROL BOX | 1 | |
| 11 | 94050-08070 | NUT, FLANGE, 8MM | 1 | |
| 12 | 95701-08045-07 | BOLT, FLANGE, 8X45 | 1 | |
| 13 | 96300-08018-08 | BOLT, FLANGE, 8X18 | 4 | |
