F-26 - CANISTER
HONDA SP125 CBF125MEFT · 10 parts
Parts in This Assembly (10)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17310-K0N-DJ1 | CANISTER COMP | 1 | |
| 2 | 17411-K0N-D00 | CASE, CANISTER | 1 | |
| 3 | 17412-K0N-D00 | TUBE, CHARGE | 1 | |
| 4 | 17413-K0N-D00 | TUBE ASSY. A, PURGE | 1 | |
| 5 | 17414-K0V-A00 | TUBE COMP., DRAIN | 2 | |
| 6 | 17415-K0N-D00 | TUBE ASSY. B, PURGE | 1 | |
| 7 | 36162-K0N-601 | VALVE, PURGE CONTROL SOLENOID | 1 | |
| 9 | 90651-KWP-F00 | CLIP, TUBE(B7) | 2 | |
| 10 | 90652-KWP-F00 | CLIP, TUBE(B8) | 5 | |
| 11 | 93500-05010-0H | SCREW, PAN, 5X10 | 2 | |
