F-1 - HEADLIGHT
HONDA SP125 CBF125MEFT · 5 parts
Parts in This Assembly (5)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33100-K1K-D51 | HEADLIGHT ASSY. | 1 | |
| 2 | 33128-GBL-003 | NUT, SPECIAL | 1 | |
| 3 | 53209-GAH-000 | CLIP, HEADLIGHT | 2 | |
| 4 | 90101-K1E-600 | BOLT, ADJUSTING | 1 | |
| 5 | 90307-K21-900 | WASHER, LOCK, 6MM | 1 | |
