F-9 - STEERING HANDLE/HANDLE COVER
HONDA Activa125 SCV125K · 22 parts
Parts in This Assembly (22)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 53100-K24-900 | HANDLE COMP., STEERING | 1 | |
| 1 | 53100-K24-G10 | HANDLE COMP., STEERING | 1 | |
| 2 | 53124-KWP-900 | COLLAR HANDLE SET | 1 | |
| 3 | 53202-K24-920 | CUSHION, FR. HANDLE | 1 | |
| 4 | 53204-K24-900ZA | VISOR, METER *NH1* BLACK | 1 | |
| 5 | 53206-K24-G00ZA | COVER, HANDLE RR. *NH1* BLACK | 1 | |
| 6 | 53207-K24-G00 | CAP, HEADLIGHT SWITCH | 1 | |
| 7 | 53208-K24-900ZA | COVER COMP., METER GARNISH *NH35M* CLOUD SILVER METALLIC | 1 | |
| 8 | 53250-K24-920ZE | COVER COMP., HANDLE FR *YR343M* MAT CRUST METALLIC | 1 | |
| 8 | 53250-K24-G10ZE | COVER COMP., HANDLE FR.*NHB63P* PEARL AMAZING WHITE | 1 | |
| 8 | 53250-K24-G10ZD | COVER COMP., HANDLE FR.*NH1* BLACK | 1 | |
| 8 | 53250-K24-G10ZC | COVER COMP., HANDLE FR.*PB375M* MIDNIGHT BLUE METALLIC | 1 | |
| 8 | 53250-K24-G10ZB | COVER COMP., HANDLE FR.*R329M* REBEL RED METALLIC | 1 | |
| 8 | 53250-K24-G10ZA | COVER COMP., HANDLE FR. *YR343M* MAT CRUST METALLIC | 1 | |
| 8 | 53250-K24-920ZA | COVER COMP., HANDLE FR *R329M* REBEL RED METALLIC | 1 | |
| 8 | 53250-K24-920ZB | COVER COMP., HANDLE FR *PB375M* MIDNIGHT BLUE METALLIC | 1 | |
| 8 | 53250-K24-920ZC | COVER COMP., HANDLE FR *NH1* BLACK | 1 | |
| 8 | 53250-K24-920ZD | COVER COMP., HANDLE FR *NHB63P* PEARL AMAZING WHITE | 1 | |
| 9 | 86150-KWS-601 | EMBLEM, PRODUCT(SJS) | 1 | |
| 11 | 90502-KWP-900 | COLLAR B HNDL SET | 1 | |
| 12 | 93891-05016-07 | SCREW WASH 5X16 | 2 | |
| 14 | 95801-10055-08 | BOLT, FLANGE, 10X55 | 1 | |
