F-6 - FRONT FENDER
HONDA Activa125 SCV125G · 7 parts
Parts in This Assembly (7)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33740-KTE-601 | REFLECTOR, FR. SIDE REFLEX | 2 | |
| 2 | 61103-KRY-900 | COLLAR, A FR.FENDER | 3 | |
| 3 | 61120-K24-900ZE | FENDER B, FR. *NH1* BLACK | 1 | |
| 4 | 61100-K24-900ZZ | FENDER A, FR. | 1 | |
| 5 | 61300-K24-900 | STAY COMP., FR. FENDER | 1 | |
| 6 | 90113-KVT-901 | BOLT, SPECIAL HEX., 6X20 | 2 | |
| 7 | 90302-KTE-911 | NUT FLANGE PT 6MM | 2 | |
