FOP-1 - INNER BOX
HONDA Activa SCV110H · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 75581-KPL-900 | SET SPG LOCK KEY | 1 | |
| 2 | 81130-KWP-900 | BOX ASSY., INNER | 1 | |
| 3 | 81134-KWP-900 | OUTER, INNER BOX | 1 | |
| 4 | 81135-KWP-900 | INNER, INNER BOX | 1 | |
| 5 | 81137-KWP-900 | SEAL INNER BOX | 1 | |
| 6 | 81138-KWP-900 | SEAL, OUTER INNER | 1 | |
| 7 | 81140-KWP-900 | BOX SET, INNER | 1 | |
| 8 | 81141-KWP-900 | LID, INNER BOX | 1 | |
| 9 | 81143-GC8-000 | PIN, INNER BOX LID | 2 | |
| 10 | 81145-KPL-900 | KEY SET, INNER BOX | 1 | |
| 11 | 90344-KRP-900 | NUT CLIP 5MM | 4 | |
| 12 | 93404-06020-08 | BOLT-WASHER, 6X20 | 1 | |
| 13 | 93903-25180 | SCREW, TAPPING, 5 X 10 | 4 | |
| 14 | 93903-25580 | SCREW TAPPING 5X25 | 6 | |
