F-38-11 - REAR COMBINATION LIGHT(LUMAX)
HONDA Activa SCV110H · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 32920-KWP-F02 | CLIP A, HARNESS | 1 | |
| 2 | 33700-KWP-F02 | LIGHT ASSY., RR. COMBINATION | 1 | |
| 3 | 33706-KWP-F02 | PACKING A, SEAL | 1 | |
| 4 | 33707-KWP-F02 | PACKING B, SEAL | 1 | |
| 5 | 33710-KWP-F02 | TAILLIGHT UNIT(LUMAX) | 1 | |
| 6 | 33715-KWP-F02 | SOCKET COMP.(LUMAX) | 1 | |
| 7 | 33720-KWP-F02 | LENS COMP., TAILLIGHT(LUMAX) | 1 | |
| 11 | 93901-34410 | SCREW, TAPPING, 4X16 | 1 | |
