F-20-30 - FRONT WHEEL(SCV110G-2ID,ID)
HONDA Aviator SCV110GK · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 42753-KWP-E01 | VALVE, RIM(TRITON) | 1 | |
| 2 | 44301-KTR-700 | AXLE, FR. WHEEL | 1 | |
| 3 | 44311-KVT-900 | COLLAR, FR. WHEEL SIDE | 1 | |
| 4 | 44620-KPL-900 | COLLAR FR WHEEL DISTANCE | 1 | |
| 5 | 44650-KVT-G00 | WHEEL SUB ASSY., FR. | 1 | |
| 6 | 44711-K74-N02 | TIRE, FR.(CEAT)(90/90-12 54J). | 1 | |
| 6 | 44711-KVT-D03 | TIRE, FR.(TVS)(90/90-12 54J).. | 1 | |
| 6 | 44711-KVT-D01 | TIRE, FR.(MRF)(90/90-12 54J) | 1 | |
| 7 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 8 | 90912-KPL-900 | BEARING BALL RADIAL 6201(U) | 2 | |
| 9 | 91251-KWP-901 | SEAL DUST 20X32X5 | 1 | |
