F-6 - FRONT COVER(1)
HONDA Dio SCV110FD · 25 parts
Parts in This Assembly (25)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 61104-428-000 | COLLAR, FR, FENDER | 2 | |
| 1 | 61104-428-010 | COLLAR, FR. FENDER(WHITE)..... (FOR RR.) | 2 | |
| 1 | 61104-428-730 | COLLAR, FR. FENDER(BLACK)..... (FOR RR.) | 2 | |
| 2 | 64200-KZK-901ZA | COVER SET, FR.(WL) *TYPE5* | 1 | |
| 2 | 64200-KZK-901ZB | COVER SET, FR.(WL) *TYPE4* | 1 | |
| 2 | 64200-KZK-901ZC | COVER SET, FR.(WL) *TYPE3* | 1 | |
| 2 | 64200-KZK-901ZD | COVER SET, FR.(WL) *TYPE2* | 1 | |
| 2 | 64200-KZK-901ZE | COVER SET, FR.(WL) *TYPE1* | 1 | |
| 2 | 64200-KZK-900ZA | COVER SET, FR.(WL) *TYPE5* | 1 | |
| 2 | 64200-KZK-900ZB | COVER SET, FR.(WL) *TYPE4* | 1 | |
| 2 | 64200-KZK-900ZC | COVER SET, FR.(WL) *TYPE3* | 1 | |
| 2 | 64200-KZK-900ZD | COVER SET, FR.(WL) *TYPE2* | 1 | |
| 2 | 64200-KZK-900ZE | COVER SET, FR.(WL) *TYPE1* | 1 | |
| 3 | 64303-KZK-900 | STAY, FR. NUMBER PLATE | 1 | |
| 4 | 64305-KZK-900ZA | COVER, FR. LOWER *NH411M* FORCE SILVER METALLIC | 1 | |
| 4 | 64305-KZK-900ZB | COVER, FR. LOWER *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 4 | 64305-KZK-900ZC | COVER, FR. LOWER *NH105* MAT BLACK(#15-#20) | 1 | |
| 5 | 81131-KZK-900ZA | COVER, INNER *NH1* BLACK | 1 | |
| 6 | 84703-425-000 | RUBBER TAIL LIGHT (MOUNT) | 2 | |
| 7 | 90107-KTL-740 | SCREW, COWL SETTING(A) | 2 | |
| 10 | 90683-GAZ-003 | CLIP, TRIM | 2 | |
| 12 | 94050-06080 | NUT, FLANGE, 6MM | 2 | |
| 13 | 95701-06025-00 | BOLT, FLANGE, 6X 25 | 2 | |
| 13 | 95702-06025-00 | BOLT, FLANGE, 6X25 | 2 | |
| 14 | 81132-KZK-900 | RUBBER, KEY CYLINDER | 1 | |
