F-16 - AIR SUCTION VALVE
HONDA Dio SCV110FD · 13 parts
Parts in This Assembly (13)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17316-611-000 | CLIP, BREATHER TUBE | 2 | |
| 2 | 17622-GB7-900 | RUBBER, CUSHION | 2 | |
| 3 | 18600-KWP-901 | VALVE ASSY,AIR SUCTION | 1 | |
| 4 | 18651-KPL-840 | TUBE, AIR SUCTION VALVE | 1 | |
| 5 | 18652-KZK-900 | HOSE, AIR SUCTION VALVE | 1 | |
| 6 | 18653-KWP-900 | TUBE ASV VACUUM | 1 | |
| 7 | 50142-KPL-840 | STAY, USV | 1 | |
| 8 | 90501-KC2-750 | WASHER, REGULATOR SETTING | 2 | |
| 9 | 90682-SA0-670 | CLAMP CANIASTER HOSE | 2 | |
| 10 | 93404-06030-08 | BOLT WASH 6X30 | 2 | |
| 12 | 95002-02070 | CLIP, B-7 TUBE | 2 | |
| 13 | 95702-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
| 13 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 2 | |
