FOP-1 - SARI STEP SET
HONDA Navi NVA110BK · 11 parts
Parts in This Assembly (11)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 83521-KPL-900 | PLATE, SARI STEP | 1 | |
| 2 | 83522-KPL-900 | STEP, PIN A, SARI | 1 | |
| 3 | 83523-KPL-900 | STEP, PIN B, SARI | 1 | |
| 4 | 83524-KPL-900 | SPRING, STEP | 1 | |
| 5 | 83526-KPL-900 | STOPPER, STEP RUBBER | 1 | |
| 6 | 83540-K74-N00 | STEP COMP., SARI | 1 | |
| 7 | 83560-K74-N00 | STEP SET, SARI | 1 | |
| 8 | 94305-30142 | PIN, SPRING 3X14 | 1 | |
| 9 | 94305-30282 | PIN, SPRING 3X28 | 1 | |
| 10 | 95701-10060-00 | BOLT, FLANGE, 10X60 | 1 | |
| 11 | 95701-10080-00 | BOLT, FLANGE, 10X80 | 1 | |
