F-28 - SERVO MOTOR
HONDA Africa Twin CRF1100DL2N · 6 parts
Parts in This Assembly (6)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31420-MKS-E01 | MOTOR ASSY., SERVO | 1 | |
| 2 | 77205-KM4-000 | GROMMET, SEAT SETTING | 2 | |
| 3 | 80108-MKS-E00 | COVER, MOTOR | 1 | |
| 6 | 91565-S0X-003 | CLIP, COUPLER(DARK GREEN) | 1 | |
| 7 | 93903-25220 | SCREW, TAPPING, 5X12 | 3 | |
| 8 | 94103-06800 | WASHER, PLAIN 6 MM | 2 | |
