F-23 - SEAT
HONDA CB300R CBF300NAN · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33706-KAN-960 | COLLAR, TAILLIGHT MOUNTING | 2 | |
| 2 | 61304-415-000 | RUBBER, HEADLIGHT CASE MOUNTING | 2 | |
| 3 | 75581-MGP-D60 | PLATE, LOCK KEY SETTING | 1 | |
| 4 | 77100-K0A-E10ZA | SEAT COMP., SINGLE *TYPE1* | 1 | |
| 5 | 77205-K45-N00 | RUBBER, SEAT SETTING | 2 | |
| 6 | 77205-KPP-T00 | RUBBER, SEAT SETTING | 1 | |
| 7 | 77206-KPK-900 | RUBBER, SEAT CUSHION | 4 | |
| 8 | 77215-KW7-900 | RUBBER C, SEAT SETTING | 2 | |
| 9 | 77220-K94-T01 | HOOK, SEAT CATCH | 1 | |
| 10 | 77236-K94-T00 | WASHER, SEAT LOCK | 1 | |
| 11 | 77239-K0A-E11 | KEY, SEAT LOCK(WAVE) | 1 | |
| 12 | 77300-K0A-E10ZA | SEAT COMP., PILLION *TYPE1* | 1 | |
| 13 | 96001-06012-00 | BOLT,FLANGE,SH,.6 X 12 | 1 | |
| 14 | 96600-06025-08 | BOLT, SOCKET, 6X25 | 2 | |
