F-24 - SIDE COVER
HONDA SP160 CBF160FSR · 12 parts
Parts in This Assembly (12)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 83500-K0E-DF0ZC | COVER SET A, R. SIDE(WL) *NH303M* | 1 | |
| 1 | 83500-K0E-DF0ZE | COVER SET A, R. SIDE(WL) *NHB05P* | 1 | |
| 1 | 83500-K0E-DF0ZG | COVER SET A, R. SIDE(WL) *NHC31M* | 1 | |
| 2 | 83511-K0E-DF0 | COVER B, R. SIDE | 1 | |
| 3 | 83600-K0E-DF0ZC | COVER SET A, L. SIDE(WL) *NH303M* | 1 | |
| 3 | 83600-K0E-DF0ZE | COVER SET A, L. SIDE(WL) *NHB05P* | 1 | |
| 3 | 83600-K0E-DF0ZG | COVER SET A, L. SIDE(WL) *NHC31M* | 1 | |
| 4 | 83611-K0E-DF0 | COVER B, L. SIDE | 1 | |
| 5 | 90116-SP0-003 | CLIP, BUMPER SEAL | 2 | |
| 6 | 90134-KPP-T00 | SCREW, PAN, 5X14 | 2 | |
| 7 | 90666-K59-A11 | CLIP, SNAP FITTING(PO) | 4 | |
| 8 | 93903-24320 | SCREW, TAPPING, 4X12 | 4 | |
