F-14-40 - FRONT WHEEL
HONDA SP160 CBF160FSR · 23 parts
Parts in This Assembly (23)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 2 | 42753-KWF-901 | VALVE, RIM(TRITON) | 1 | |
| 2 | 42753-K24-G11 | VALVE, RIM(ACCURA) | 1 | |
| 3 | 44301-KSP-900 | AXLE, FRONT WHEEL | 1 | |
| 4 | 44311-KSP-900 | COLLAR, FR. WHEEL SIDE | 2 | |
| 5 | 44620-K67-900 | COLLAR, FR. AXLE DISTANCE | 1 | |
| 6 | 44650-K0E-Y01ZA | WHEEL SUB ASSY., FR. *NH303M*. MAT AXIS GRAY METALLIC | 1 | |
| 7 | 44711-KSP-B02 | TIRE, FR.(MRF)(80/100-17 46P). | 1 | |
| 7 | 44711-K0E-D21 | TIRE, FR.(TVS) (80/100-17 M/C 46P) | 1 | |
| 8 | 45251-K43-901 | DISK, FR. BRAKE(YUTAKA) | 1 | |
| 9 | 90105-KSP-870 | BOLT, FRONT DISK, 8 X 24 | 5 | |
| 10 | 90306-KTE-911 | NUT, CASTLE, 12 MM | 1 | |
| 11 | 91051-K15-901 | BEARING, RADIAL BALL, 6301UU (SKF) | 2 | |
| 11 | 91051-K21-902 | BEARING, RADIAL BALL, 6301UU (FAG) | 2 | |
| 11 | 91051-K21-903 | BEARING, RADIAL BALL, 6301UU (NEI) | 2 | |
| 12 | 91251-KPH-901 | DUST SEAL, 21 X 37 X 7 | 2 | |
| 13 | 38515-K43-D20 | GUIDE, SENSOR CORD | 1 | |
| 14 | 38520-K0E-DF1 | SENSOR, FR. WHEEL SPEED | 1 | |
| 15 | 44515-K43-D20 | RING, FR. PULSER | 1 | |
| 17 | 90106-K43-D20 | BOLT, FLANGE, 6X14(SH) | 1 | |
| 18 | 90131-KYJ-610 | BOLT, TORX, 5X10 | 3 | |
| 19 | 96300-06020-07 | BOLT, FLANGE, 6X20 | 1 | |
| 20 | 38517-MGE-003 | CLAMP, ABS CORD(D12) | 1 | |
| 21 | 91565-SEL-003 | CLIP, COUPLER(BLACK) | 1 | |
