F-43 - FRONT COWL
HONDA CB Unicorn 160 CBF160AL · 14 parts
Parts in This Assembly (14)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 61301-K1K-D00ZA | COWL, FR. *R355M* IMPERIAL RED METALLIC | 1 | |
| 1 | 61301-K1K-D00ZB | COWL, FR. *NH303M* MAT AXIS GRAY METALLIC | 1 | |
| 1 | 61301-K1K-D00ZC | COWL, FR. *NHB05P* PEARL IGNEOUS BLACK | 1 | |
| 1 | 61301-K1K-D00ZE | COWL, FR. *NHC45M* SPEAR SILVER METALLIC | 1 | |
| 2 | 61310-K1K-D00 | COVER, HEADLIGHT RR. | 1 | |
| 3 | 64100-K1K-D00ZA | WINDSCREEN SET(WL) *TYPE1* | 1 | |
| 4 | 67111-K1K-D00 | GARNISH, SCREEN | 1 | |
| 5 | 77267-KTR-900 | RUBBER, COWL | 2 | |
| 6 | 90101-GE0-000 | SCREW, HINGE PATCH | 4 | |
| 8 | 90344-KTE-910 | NUT, CLIP, 4MM | 2 | |
| 9 | 90654-K0L-D00 | NUT, CLIP, 5MM | 6 | |
| 10 | 90666-SDA-A01 | CLIP , SNAP FIT (PO) | 3 | |
| 11 | 90671-KSP-860 | GROMMET, PANEL | 1 | |
| 12 | 93903-24380 | SCREW TAPPING, 4 X 12 | 5 | |
