F-23-10 - REAR COWL
HONDA CB Unicorn 160 CBF160AL · 15 parts
Parts in This Assembly (15)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17232-KYJ-900 | COLLAR, AIR CLEANER MOUNTING | 4 | |
| 2 | 77215-K1K-D00ZA | COWL SET, R. RR.(WL) *TYPE4* | 1 | |
| 2 | 77215-K1K-D00ZB | COWL SET, R. RR.(WL) *TYPE3* | 1 | |
| 2 | 77215-K1K-D00ZC | COWL SET, R. RR.(WL) *TYPE2* | 1 | |
| 2 | 77215-K1K-D00ZD | COWL SET, R. RR.(WL) *TYPE1* | 1 | |
| 3 | 77225-K1K-D00ZB | COWL SET, L. RR.(WL) *TYPE3* | 1 | |
| 3 | 77225-K1K-D00ZC | COWL SET, L. RR.(WL) *TYPE2* | 1 | |
| 3 | 77225-K1K-D00ZD | COWL SET, L. RR.(WL) *TYPE1* | 1 | |
| 3 | 77225-K1K-D00ZA | COWL SET, L. RR.(WL) *TYPE4* | 1 | |
| 4 | 77280-K1K-D00ZA | COWL SET, RR. CENTER(WL) *TYPE4* | 1 | |
| 4 | 77280-K1K-D00ZB | COWL SET, RR. CENTER(WL) *TYPE3* | 1 | |
| 4 | 77280-K1K-D00ZC | COWL SET, RR. CENTER(WL) *TYPE2* | 1 | |
| 4 | 77280-K1K-D00ZD | COWL SET, RR. CENTER(WL) *TYPE1* | 1 | |
| 5 | 83545-KCJ-690 | RUBBER, SIDE COVER | 2 | |
| 8 | 93903-35280 | SCREW, TAPPING, 5 X 12 | 2 | |
