F-10 - FRONT FENDER
HONDA CB Unicorn 160 CBF160AL · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 45451-KTE-D00 | GUIDE, FR. FENDER CABLE | 1 | |
| 2 | 61110-K1K-D00ZB | FENDER SET, FR.(WL) *TYPE3* | 1 | |
| 2 | 61110-K1K-D00ZC | FENDER SET, FR.(WL) *TYPE2* | 1 | |
| 2 | 61110-K1K-D00ZD | FENDER SET, FR.(WL) *TYPE1* | 1 | |
| 2 | 61110-K1K-D00ZA | FENDER SET, FR.(WL) *TYPE4* | 1 | |
| 3 | 61102-K1K-D00 | STAY, FR. FENDER | 1 | |
| 4 | 61103-KRY-900 | COLLAR, A FR.FENDER | 4 | |
| 5 | 61105-KRY-900 | RUBBER, FR.FENDER MTG. | 4 | |
| 6 | 96001-06032-00 | BOLT, FLANGE, SH., 6 X 32 | 4 | |
