F-3-10 - MIRROR
HONDA CB Unicorn CBF150M7 · 5 parts
Parts in This Assembly (5)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 88114-KFN-950 | CAP, LOCK NUT | 2 | |
| 3 | 88210-KSP-900 | MIRROR COMP., R. | 1 | |
| 6 | 88220-KSP-900 | MIRROR COMP., L. | 1 | |
| 8 | 90003-MY5-720 | BOLT,ADPT.10MM | 2 | |
| 9 | 90201-MW3-620 | NUT, HEX., 10MM | 2 | |
