F-27-2 - BATTERY(3)
HONDA CB Unicorn CBF150M7 · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 31500-KCH-650 | BATTERY(YB2.5L-C) | 1 | |
| 2 | 31502-KTE-910 | TUBE, BATTERY BREATHER | 1 | |
| 3 | 50380-KSP-970 | BOX, BATTERY | 1 | |
| 4 | 50381-KSP-970 | BAND, BATTERY | 1 | |
| 5 | 50385-KTE-910 | TRAY, BATTERY | 1 | |
| 6 | 50386-KSP-970 | COVER, BATTERY | 1 | |
| 7 | 50388-KTE-910 | TUBE, BATTERY TRAY | 1 | |
| 9 | 90602-KPL-900 | CLAMP, D12 TUBE | 1 | |
