F-33-1 - CAUTION LABEL(2)
HONDA CBF Stunner CBF1259 · 8 parts
Parts in This Assembly (8)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 87505-KWF-960 | LABEL, TIRE | 1 | |
| 1 | 87505-KWF-900 | LABEL, TIRE | 1 | |
| 2 | 87506-KTE-930 | MARK, BATTERY CAUTION | 1 | |
| 3 | 87507-MCR-A20 | LABEL, DRIVE CHAIN | 1 | |
| 3 | 87507-KTE-910 | LABEL DRIVE CHAIN | 1 | |
| 4 | 87522-MAB-600 | LABEL, VISOR CAUTION | 1 | |
| 5 | 87560-MZ0-670 | LABEL, DRIVE | 1 | |
| 6 | 87509-KWP-900 | LABEL,AIR/C ELEMENT NOTICE | 1 | |
