F-29-1 - WIRE HARNESS(THROTTLE BODY)
HONDA CBF Stunner CBF1259 · 17 parts
Parts in This Assembly (17)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 30510-KTY-D31 | COIL COMP., IGNITION | 1 | |
| 2 | 30520-ML7-000 | SPACER IGN. COIL | 2 | |
| 3 | 30700-KWF-950 | CAP ASSY., NOISE SUPPRESSOR | 1 | |
| 4 | 31600-KSP-861 | RECTIFIER COMP., REGULATOR | 1 | |
| 5 | 31700-124-008 | RECTIFIER ASSY., SILICON(SHINDENGEN) | 1 | |
| 6 | 32100-KWF-960 | HARNESS, WIRE | 1 | |
| 7 | 32606-GEV-761 | CAP, DUMMY(4P)(RED) | 1 | |
| 9 | 35160-KWF-951 | SENSOR ASSY., BANK ANGLE | 1 | |
| 10 | 35162-MFA-D01 | COLLAR | 2 | |
| 11 | 35163-MBZ-C50 | GROMMET | 2 | |
| 15 | 38306-GE7-000 | SUSPENSION, WINKER RELAY | 1 | |
| 18 | 38770-KWF-961 | PGM-FI UNIT | 1 | |
| 19 | 38771-KTW-900 | CUSHION, PGM-FI UNIT | 1 | |
| 21 | 90651-KV6-003 | BAND WIRE | 1 | |
| 22 | 92101-06020-4J | BOLT, HEX., 6 X 20 | 2 | |
| 23 | 93891-04022-07 | SCREW-WASHER, 4X22 | 2 | |
| 27 | 98200-41000 | FUSE, MINI(10A) | 3 | |
