F-11-3 - FRONT WHEEL(4)
HONDA CBF Stunner CBF1259 · 9 parts
Parts in This Assembly (9)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 6 | 44680-410-000 | RETAINER, GEAR BOX | 1 | |
| 8 | 44800-KSP-900ZC | BOX ASSY., SPEEDOMETER GEAR *NH105* MAT BLACK(#15-#20) | 1 | |
| 9 | 44804-KSP-901 | GEAR, SPEEDOMETER | 1 | |
| 10 | 44809-KPL-900 | WASHER, SPEEDOMETER GEAR | 1 | |
| 11 | 45251-KVE-901 | DISC, FRONT BRAKE | 1 | |
| 12 | 90105-KSP-870 | BOLT, FRONT DISK, 8 X 24 | 6 | |
| 14 | 96150-63010-10 | BEARING, BALL RADIAL, 6301 (UU) | 2 | |
| 16 | 91258-410-013 | DUST SEAL, 40X50X5(ARAI) | 1 | |
| 17 | 44650-KSP-870 | WHEEL SUB ASSY., FR. | 1 | |
