F-36 - TAILLIGHT
HONDA Livo CBF110SBES · 6 parts
Parts in This Assembly (6)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 33703-K1C-D01 | BASE COMP., TAILLIGHT | 1 | |
| 2 | 33704-K1C-D01 | SOCKET COMP., TAILLIGHT | 1 | |
| 5 | 33707-K1C-D00 | COLLAR, TAILLIGHT MOUNTING | 2 | |
| 6 | 34907-KPP-T01 | BULB, TAIL & STOP LIGHT (12V 21/5W) | 1 | |
| 7 | 80102-K1C-D00 | PLATE, TAILLIGHT SETTING | 2 | |
| 8 | 83601-MN5-000 | GROMMET SIDE COVER | 1 | |
