F-4 - HANDLE LEVER/SWITCH/CABLE
HONDA CB350 CB350CR · 19 parts
Parts in This Assembly (19)
| Ref # | Part Number | Description | Qty | |
|---|---|---|---|---|
| 1 | 17910-K0Z-J01 | CABLE COMP. A, THROTTLE | 1 | |
| 2 | 17920-K0Z-J01 | CABLE COMP. B, THROTTLE | 1 | |
| 3 | 22870-K3R-D01 | CABLE COMP., CLUTCH | 1 | |
| 4 | 35130-K0Z-D01 | SWITCH ASSY., STARTER & ENGINE STOP & HAZARD | 1 | |
| 5 | 35200-K0Z-D01 | SWITCH ASSY., WINKER | 1 | |
| 6 | 35330-KWS-901 | SWITCH ASSY., CLUTCH | 1 | |
| 7 | 53140-K3R-D00 | GRIP COMP., THROTTLE | 1 | |
| 8 | 53166-K3R-D00 | GRIP, L. HANDLE | 1 | |
| 13 | 90129-K0Z-900 | SCREW-WASHER, 5X16 | 2 | |
| 14 | 90133-K0Z-900 | SCREW-WASHER, 5X25 | 2 | |
| 18 | 35152-KRY-970 | COVER CLUTCH SW.TERMINAL | 1 | |
| 19 | 45517-KCW-870 | HOLDER, MASTER CYLINDER | 1 | |
| 20 | 53172-402-700 | COVER, L. HANDLE LEVER | 1 | |
| 21 | 53172-KYJ-900 | BRACKET, HANDLE LEVER | 1 | |
| 22 | 53178-K0Z-D00 | LEVER COMP., L. HANDLE | 1 | |
| 23 | 53192-K0A-DB0 | BOLT, CLUTCH WIRE ADJUSTING | 1 | |
| 24 | 90113-KSP-901 | BOLT, L. HANDLE LEVER PIVOT | 1 | |
| 25 | 90321-315-670 | NUT, FIXING | 1 | |
| 26 | 96001-06022-07 | BOLT, FLANGE, SH.6X22 | 2 | |
